ABB Cell Phone Door Entry Integration Kit

$1,148.48
SKU: ABBM20353

Order now and we'll ship usually within 1-2 business days.

Shop More From ABB

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Product Description

ABB-Welcome Cell Phone Door Entry Integration Kit includes:

One Mini outdoor station, 1 round pushbuttons

  • Compact size, surface mounted
  • 1 round pushbutton
  • Clean design with integrated status display
  • Up to 2 locks connections

One Mini system controller

  • As the "brain" of the individual system, it manages the communications between the outdoor station and the indoor station.
  • Two working modes: "all on" and "one on."
  • If in "all on" mode, and the apartment contains more than 1 video indoor station, all the screens in the apartment will be on while only one is on if in "one on" mode.
  • It can also serve as auxiliary BUS power supply when connected to gateway in certain mode.
  • 1 LED for normal working condition indication.
  • Overheat, short-circuit and lightning protection.

One IP Gateway

  • Enables Smartphones (iOS and Android) and tablet by installing the app as video indoor station.
  • Supports both WIFI and remote access under 3G/4G with the help of service provider.
  • Enables the integration with ABB Comfort touch as indoor station.
  • PC interface efficiently programs telephone gateway products.

In The Box:

  • 1 x Outdoor Station (M21311P1-A)
  • 1 x Controller (M2301)
  • 1 x Gateway (3342-500)

Tech Specs

  • Part Number: M20353
  • Warranty: 2 Years

Mini Outdoor Station, 1-Button (M21311P1-A)

  • Dimensions: 3.89 x 6.61 x 1.02 inches

IP Gateway (83342-500)

  • Operating Temperature: -13° to 131°F (-25° to 55°C)
  • Protection: IP20
  • Single-Wire Clamps: 2 x 0.28 mm2 – 2 x 1 mm2
  • Fine-Wire Clamps: 2 x 0.28 mm2 – 2 x 1 mm2
  • Bus Input Voltage: 20-30VDC
  • Size: 10 TE
Mini System Controller (M2301)

  • Operating Temperature: -13° to 131°F (-25° to 55°C)
  • Storage Temperature: -40° to 158°F (-40° to 70°C)
  • Protection: IP20
  • Single-Wire Clamps: 2 x 0.28 mm2 – 2 x 1 mm2
  • Fine-Wire Clamps: 2 x 0.28 mm2 – 2 x 1 mm2
  • Mains Voltage: 100-240V, 50/60 Hz, 1A
  • Bus Voltage: 28 ± 2VDC, 0.65A
  • Size: 4U
  • Dimensions: 3.54 x 2.83 x 2.56 inches

Requirements:

  • DSL-6000 Internet connection or faster
  • Minimum 3G (UMTS) mobile Internet
  • Android 4.0 or higher, or iOS 4 or higher

System Capacity

  • 9 Guard Units per System
  • 60 Buildings per System
  • 250 Indoor Stations per Building
  • 9 Outdoor Stations per Building (including gate and other outdoor stations)
  • 2 Locks per Outdoor Station
