Sensaphone FGD-0303 Vibration Sensor

$314.10
SKU: PHFGD0303

Order now and we'll ship usually within 3-5 business days.

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Product Description

Implementation of continuous vibration monitoring has never been easier. Vibration on industrial equipment can be continuously monitored for unusual operating conditions and potential failure. The Sensaphone Vibration Monitor is designed to be permanently mounted on industrial equipment and continuously monitor the changes in a machine's vibration level. Detecting these changes early on prevents machinery from catastrophic failure, secondary damage, and expensive down time.

The sensor continuously monitors real-time RMS vibration velocity and provides an analog output of the velocity to the Sensaphone. The sensor comes with a 5m cable and is available with an optional magnetic mounting base (not included).

In The Box:

  • Vibration sensor
  • 5m cable

NOTE: Requires a 24VDC power supply (FGD-0070). Available with optional magnetic mounting foot – FGD-0303-MOUNT.

Available for sale only in the U.S.

Tech Specs

  • Part Number: FGD-0303
  • Sensor Series: 4-20mA
  • Cable Length: 16.4 feet (5m)
  • Input Circuit: 1 x analog 4-20mA
  • Measuring Range: 0 to 25 RMS (mm/s)
  • Frequency Range: 10 Hz to 1,000 Hz
  • Protection: IP 67 / IP 68 / IP 69K
  • Operating Voltage: 9.6 to 32 DC
  • Ambient Temperature Range: -13° to 176°F (-25° to 80°C)
