2GIG 4-Button Key Ring Remote
Product Description
The 2GIG-KEY2-345 is a 4-button key ring remote. The key fob enables you to turn the 2GIG system on and off before entering the home or after exiting. If there is an emergency, you can turn on the siren and automatically call the central monitoring station. If lamp modules have been installed, you can use the key fob to turn all system-controlled lights on or off via the open collector output. Use with the 2GIG-GDR1-345 to open a garage door. The key fob is a lithium coin battery-powered, wireless key fob designed to fit on a keychain, in a pocket, or in a purse. It provides a convenient option for the following system operations:
- Arm the system (doors, windows, and motion sensors)
- Arm the system with no entry delay (if programmed)
- Disarm the system
- Trigger panic alarms
- Transmits 345 MHz
- Auxiliary output and emergency functions
- Turn system-controlled lights on or off (via the open collector output)
- Other open collector output functions (if applicable)
- Use with the 2GIG-GDR1-345 to open a garage door (see the 2GIG-GDR1-345 Install Instructions)
- ETL Listed
In The Box:
- Key fob
- Key ring
- Lithium battery
Tech Specs
- Part Number: 2GIG-KEY2-345
- Wireless Signal Range: 350 feet, open air, with 2GIG Wireless Control Panel
- Code Outputs: Arm; Disarm; Panic; Relay Control
- Transmitter Frequency: 345.000 MHz (crystal controlled)
- Transmitter Frequency Tolerance: ±15kHz
- Transmitter Bandwidth: 24kHz
- Modulation Type: Amplitude Shift Keying-On/Off Keying (ASK-OOK)
- Unique ID Codes: Over one million different code combinations
- Supervisory Interval: 70 minutes
- Peak Field Strength: Typical 40,000 uV/m at 3m
- Dimensions: 1.23(L) x 2.26(W) x 0.45(H) inches (3.12 x 5.74 x 1.14 cm)
- Weight: 0.65 ounces (18.4 g)
- Housing Material: ABS plastic
- Color: White
- Operating Temperature: 32° to 104° F (0° to 40° C)
- Relative Humidity: 5 to 95 percent Non-Condensing
- Battery: One Panasonic CR2032 or equivalent Lithium battery
- Included Accessories: Key ring
- Warranty: 2-Year Limited
