Channel Vision 1x1 Amplified Coaxial Splitter Module

$22.80 $33.00
SKU: CVC0310

1 available at this price.

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Pay in 4 interest-free payments. Learn More.

Product Description

Channel Vision's 10dB power injected 1x1 Amplified Coaxial Splitter Module increases the strength of the incoming cable or antenna signal for longer runs to more outputs. Unlike most Amplified Coaxial Splitters, the C-0310 uses an external power supply that can be connected directly to the unit using a coax F connector. For added versatility, an optional power injector may be used to feed power back to the amplifier from a remote location, thereby eliminating the need to install the C-0310 near a power outlet. The C-0310 easily mounts into Channel Vision's structured wiring enclosures using push and lock pins.

  • UL and CSA approved
  • 1 in 1 out 10dB Amplifier
  • Bi-directional power injected down the coax
  • 5-42MHz return path for interactive TV
  • 54-1000MHz forward path

Tech Specs

  • Bandwidth: 45-1000Mhz
  • Gain: 10dB ±1.5
  • Flatness: ±1dB
  • Return Loss: 14dB
  • Output Power: +10dB
  • Dist. X-Mod.: -70dB
  • CTB: -65dB
  • Power Supply: 12V/55mA
