Enbrighten Add-On Switch with QuickFit and SimpleWire

$21.50
SKU: JA46199

IN STOCK! Ships same business day if ordered before 3pm PT

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Product Description

Home automation is even smarter with the Enbrighten Add-On Switch with QuickFit™ and SimpleWire™. When paired with a Enbrighten or Jasco master switch, this hardwired add-on rocker switch creates an additional location to control a designated load, including lighting, fans, or water pumps, creating up to 6-way wiring systems. The switch can copy the functions of it's master switch, controlling dim/brighten or fan speed functions. This switch also can respond to wireless commands sent from automation hubs if its connected master switch is included in the smart home system. Your automation possibilities are seemingly infinite when connected to hubs from Ring, Wink, SmartThings, HomeSeer, Vera, Nexia and more.

  • Add-on rocker switch mimics control functions of a connected master switch; can be partnered with any Enbrighten smart switch, dimmer or fan control
  • This switch must be used with a Enbrighten smart control switch for Z-Wave, Zigbee or Bluetooth home automation. The smart switch or dimmer and as many as four add-on switches can be linked for up to 6-way operation
  • Improved components reduced the housing depth by up to 20 percent compared to previous models and eliminated the need for heat tabs
  • Quick Fit enhancements are the ideal smart solution for older-style switch boxes, multi-gang configurations or any other application with limited space
  • Supports 120VAC and 277VAC loads for universal applications without additional equipment
  • Switch upgrade – Easily replace any in-wall control in a multi-switch configuration to remotely turn ON/OFF and set programs for a wide range of fixtures
  • LED, CFL, incandescent and halogen – To retain the full benefit of LED, CFL, incandescent and halogen lights, the device supports all types of light sources
  • Versatile compatibility – for Z-Wave, Zigbee or Bluetooth. The add-on switch functions the same as the primary switch.
  • Requires in-wall installation with hard-wired connections – Neutral wire required. Includes white and light almond paddles (wall plate not included).

NOTES: Uses standard single-gang wallplate. For indoor use only. The switch is designed for use with permanent inwall fixtures.

Tech Specs

  • Part Number: 46199
  • UPC: 030878461993
  • Color: White paddle installed. Light Almond paddle included.
  • Size: 1-Gang
  • Power: 120/277 VAC, 60 Hz
  • Protocol: Z-Wave Plus
  • Frequency: 908.4/916 MHz
  • Load Ratings: 960W Incandescent; 1800W (15A) Resistive or 1/2 HP Motor
  • Environmental Conditions: For indoor use only.
  • Operating Temperature Range: 32 to 104° F (0 to 40° C)
  • Approvals: FCC, IC
  • Warranty: 2-Year Limited
