FIBARO Z-Wave Yubii Home Hub

$124.66
SKU: FBYH001

IN STOCK! Ships same business day if ordered before 3pm PT

Shop More From FIBARO

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Product Description

The FIBARO Z-Wave Yubii Home fits all of the power and functionality of the FIBARO Home Center 3 Lite into a smaller box for easy installation and incredible home automation control. The FIBARO Z-Wave Yubii Home can control multiple lights, appliances, gates, window coverings, HVAC, and security devices from any computer or mobile device. No matter where you are, you can remotely login to your FIBARO system to check device statuses, adjust settings, turn On/Off devices and much more through a user-friendly interface.

  • Manages up to 40 Z-Wave, Wi-Fi, and 433 MHz devices plus scenes
  • Choose from over 3000 smart devices from brands such as Yale, Honeywell, Nortek, Zipato, Bose, Philips Hue, SONOS, and more
  • Integration with NICE and ELERO devices and up to 5 software plugins
  • Voice control compatibility with Amazon Alexa, Google Assistant, and Apple Siri
  • LEDs indicate connection and power status of the hub
  • Control via mobile app for iOS and Android devices or webportal from any Internet connected computer
  • Easy DIY setup and intuitive user interface

In The Box:

  • Yubii Home
  • Power Adapter
  • Instruction Manual

NOTE: Requires an Internet router, modem, or switch and active Internet service.

Tech Specs

  • Part Number: YH-001
  • EAN: 5902701703103
  • Protocol:
    • Z-Wave Plus v2, 700 series (908.42 MHz)
    • NICE: 433 MHz, 868MHz ELERO
    • Wi-Fi: (2.4GHz) 802.11 b/g/n/a/ac
  • Max Transmitting Power:
    • Z-Wave: +9dBm
    • 433 MHz: +9dBm
    • Wi-Fi: +20 dBM
  • Wireless Range: up to 328 ft (100m)
  • LED Indicator Colors:
    • Pulsing Blue: Start-up
    • Red: Wi-Fi in Access Point mode (ready to configure)
    • Pulsing Red: disconnected from the Internet
    • Green: Connected to the Internet
  • Network Interface: 10/100/1000Base-T (Gigabit) Ethernet via RJ45 connector
  • CPU: Single-Core ARM Cortex A7 900 MHz
  • Memory: 512MB DDR3L RAM + 4GB eMMC Flash Hard Drive
  • WLAN: Connects to Wi-Fi Router via Ethernet cable
  • USB Connectors: 1 x USB 2.0
  • Power Supply: 5V DC max, 1A (power supply included)
  • Power Connector: USB Micro B
  • LED Indicators: Power, Status, Ethernet, WLAN and Z-Wave
  • Operating Temperature: 32 to 104°F (0 to 40°C)
  • Operating Humidity: max. 75% relative humidity (non-condensing)
  • Dimensions: 7.0 L x 4.33 W x 1.22 H inches (178 L x 110 W x 31 H mm)
  • Warranty: 2 Years

Product Docs
