Greenfield Automatic Security Valve Kit

$470.98 to $1,284.51
SKU: GFASVx

Please Select Option To View Availability

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

This is a heavy and/or oversized item and does not qualify for our shipping promotion.

Product Description

By connecting our Automatic Security Valve to your home automation system, the water supply to your home or business can be controlled remotely giving you total control of your water supply home or away. Our product also works great in conjunction with systems that already have water sensors, but lack the ability to actively turn off the water supply. When combined with an automation system's existing sensors, our product can react fast before significant damage can occur.

Features:

  • Fast opening and closing provides control of incoming water supply
  • Integrates with existing control systems and sensors
  • Provide 24 hours a day access to your water supply
  • Compatible with major brands of security systems
  • Significantly reduce water damage
  • Protect your home and business
  • Possible insurance discounts
  • Added property protection
  • Provides peace of mind
  • Conserves water

Actuator:

  • Actuator provides feedback when the valve is open or closed
  • Will not create explosions due to sparks from the motor
  • Extremely rugged high-torque electric actuator
  • Waterproof and Weatherproof
  • Can be installed outside

Valve:

  • Valves are pressure rated to 600 PSI (1") and 1,000 PSI (1/2" – 2") at 70 degrees F
  • ALL valves are equipped with a manual handle for emergency override
  • These valves are approved for use with water, oil, and gas applications
  • 316 stainless steel 3-piece construction, includes: body, ball, and stem
  • Approved for drinking water applications in all 50 states
  • Full port valves for maximum flow
  • Threads are FNPT

Compatible Manufacturers:

  • Leviton/HAI
  • Digital Security Controls (DSC)
  • Honeywell
  • Interlogix (GE)
  • Visonic
  • George Risk Industries (GRI)
  • Elk Products, Inc.
  • Winland Electronics
  • Resolution Products
  • Secure Wireless
  • Tane Alarm Products
  • Flair Electronics

Tech Specs

ACTUATOR

  • Housing Ratings: NEMA 6P (waterproof), NEMA 7D (ignition proof)
  • Certifications: UL listed
  • Input: 100-240V ~ 50/60Hz 1.0A MAX
  • Output: 18V 2.22A
  • Power Requirements: 12/24 VDC or 24 VAC
  • Recommended Power Supply: PS100

VALVE

  • Uniform Plumbing Code (UPC) Certification and National Plumbing Code of Canada (cUPC) Certification: Manufactured in Compliance with ASME A112.18.1-2005 / CSA B125.1-2005. Deals with plumbing fixtures and fittings and their operation, durability, and ability to meet the specified pressures and temperatures.
  • NSF/ANSI 61: Manufactured in compliance with NSF/ANSI 61-2010a. Deals with drinking water system components and the health effects.
  • California Low Lead: Manufactured in compliance with Section 116875 of the California Health and Safety Code. The wetted surfaces of pipes, pipe fittings, plumbing fittings and fixtures, as determined by a weighted average is 0.25 percent lead or less.
