Leviton Decora Smart Z-Wave Plus v2 Fan Speed Controller, Gen7

$58.33
SKU: LVZW4SF1BW

Order now and we'll ship usually within 3-5 business days.

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Product Description

The Decora Smart Z-Wave 4-Speed Fan Controller allows you to select one of 4 fan speeds or control your overhead pull-chain paddle fan when paired with a compatible Z-Wave controller. Adjust fan speed from max, high, medium, low, and off using the third-party hub's app, schedules, or voice control with a Z-Wave hub. Uses 700-Series Chipset which offers S2 security and is enabled with SmartStart. Utilize the DD00R, sold separately, for 3-way installations.

The 4 Speed Fan Controller leverages the popular Decora brand styling, along with compatible accessories including three-way devices, color change kits, and wallplates. Features true rocker action, pressing the top to turn on and the bottom to turn off. Additionally, the vertical bar on the right side of the paddle is used to increase or decrease the fan speed manually. Vanishing LEDs on the left side of the paddle show current and target fan speed with real-time feedback.

  • Quiet selection of 4 forward fans speeds and off
  • White, Single Gang Screwless Wallplate included
  • For use with one or more ceiling paddle fans with split-capacitor or shaded pole motors, not to exceed a total of 1.5A
  • Compatible with pull chain ceiling fans without electronic control
  • Ceiling fan light kits can be controlled separately by DZ6HD
  • Multi-location (3-way) control is achieved using up to 4 remote units, DD00R-DLZ
  • Z-Wave 700 Series Chipset includes S2 security and SmartStart
  • Control connected loads and lights using a Z-Wave compatible app or controller.

In The Box:

  • Z-Wave 700 Fan 4-Speed Controller
  • Single Gang Screwless Wallplate, White
  • Manual

Tech Specs

  • Part Number: ZW4SF-1BW
  • UPC: 078477588543
  • Brand: Decora Smart Z-Wave
  • Device Type: In-Wall Smart Fan Speed Controller
  • Grade: Residential
  • Hub Required: Yes
  • Ratings: 1.5A – 120VAC, 50/60Hz
  • Neutral Required: Yes
  • Termination: Wire Leads
  • Voltage: 120VAC, 50/60Hz
  • Network:
    • Wi-Fi: 802.11 a/b/g/n @ 2.4GHz
    • Security: wpa or wpa2
  • Strap Material: Metal
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Operating Humidity: 0-90% non-condensing
  • Agency Standards and Compliance: UL, FCC, CSA, NOM, Z-Wave
  • Warranty: 2-Year Limited
