Linear MegaCode Visor Transmitter, 3-Channel
Product Description
The Linear MDT-2A 3-Channel Visor Transmitter is designed for use with Linear's access control products. The MDT-2A is a three-channel device. Pressing the transmitter's left or right front button sends channel one or two. Pressing the small button on the transmitter's top sends channel three. The top button can be hidden with the top button cover supplied. Also included are lithium batteries with a five-year service life and a visor clip
The transmitter is MegaCode format, which means each transmitter is factory preprogrammed with one of over 1,000,000 codes, virtually eliminating the possibility of code duplication. Because the receiver "learns" each specific code, no unauthorized person can gain access to the system by reprogramming a transmitter.
Features:
- Compatible with all Linear access receivers and controllers
- Superior transmission range
- Factory programmed MegaCode format supports over 1,000,000 codes
- Unique "Extra" top button
- High visibility operate LED
- Visor clip included
Tech Specs
- Battery Life: Up to five years
- Frequency: 318 MHz
- Number of Codes: 1,000,000+ (MegaCode format)
- Channels: Three channel
- Power: Two 3V 2032 type lithium batteries (supplied)
- Dimensions: 1.6" W x 4.2" H x 0.8" D (41 x 107 x 20 mm)
Models compatible with the MDT-2A
- AE1000Plus: Commercial Telephone Entry System with Access Control – Four Doors
- AE2000Plus: Commercial Telephone Entry System with Access Control – Four Doors, Large Screen
- AKR-1: Exterior Digital Keypad with Radio Receiver
- AM-RPR: Remote Proximity Receiver
- AM-RRR: Remote Radio Receiver
- MDR: 1-Channel Receiver
- MDR-2: 2-Channel Receiver
- MDRG: 1-Channel Gate Receiver
- SMDRG: 1-Channel Gate Receiver
- WOR: Wiegand Output Receiver
