PCS HAI Wall Switch Dimmer, 600W/5A


Please Select Option To View Availability

WARNING: Cancer and Reproductive Harm –

Product Description

The PCS HAI UPB Wall Switch Dimmer, 600W/5A will operate LED and CFL lighting, as well as LED, CFL, incandescent, halogen, and fluorescent lighting, as well as inductive loads. The Wall Switch Dimmer has a dimming profile that provides smoother dimming and makes it easy to set the minimum dimming level to prevent flickering or drop off. Available in seven colors: white, light almond, almond, ivory, brown, gray, and black to match practically any décor.


  • Designed to operate dimmable LED and CFL "twisted" bulbs, incandescent, halogen, fluorescent bulbs, and inductive loads
  • Each unit can be a dimmer, an on/off switch or a two button transmitter depending on its programming
  • Variable fade rates for rocker switch operation and all scenes can be set between instant-on and one hour
  • Adjustable LED brightness and backlighting permits nighttime viewing and status
  • Programmable on-level with 100 dimming steps for elegant scene membership and notification for status
  • Adjustable receive sensitivity to maximize communication reliability.

In The Box:

  • Wall Switch Dimmer

NOTE: Wallplate not included.

Tech Specs

  • Part Number:
    • HAI-WS1DL-35A00-A: Almond
    • HAI-WS1DL-35A00-B: Black
    • HAI-WS1DL-35A00-BR: Brown
    • HAI-WS1DL-35A00-G: Gray
    • HAI-WS1DL-35A00-I: Ivory
    • HAI-WS1DL-35A00-LA: Light Almond
    • HAI-WS1DL-35A00-W: White
  • UPC:
    • HAI-WS1DL-35A00-LA: 811976012924
    • HAI-WS1DL-35A00-W: 811976012931
  • Incandescent Loads Dimming: Yes
  • Inductive Loads Dimming: Yes
  • Fluorescent Loads Non-dimming: Yes (configurable)
  • Power Maximum Dimming: 600W / 600VA
  • Current Maximum Non-dimming: 5A
  • Connections: 16 GA
  • LED Indicator: Yes
  • Dimensions: 4.1 X 1.75 X 1.45 in
  • Weight: 0.25 lb.
  • Mounting: Standard J box
  • Input Power: 120 ± 12 VAC
  • Input Frequency: 60 ± 3 Hz
  • Operating Temp: -40 °F to 104 °F
  • Warranty: 2-Year Limited

Product Docs
