Russound 16x16 Matrix Pre-Amplifier with Built-in Streamer
Product Description
The Russound 16-Channel Matrix Pre-Amplifier with Built-In Streamer delivers high-quality audio from 16 connected sources to up to 16 zones and sources in a home or business. This advanced multi-room audio controller allows users to enjoy different audio in separate zones or synchronize audio throughout the entire property. The integrated streamer provides access to popular audio streaming services, and facilitates use of wireless streaming protocols including Apple Airplay, Google Cast, Spotify Connect, and Bluetooth in order to make it easier than ever to play your favorite audio from any device or audio source. This Pre-Amplifier can be commanded within your home or business from a Russound XTS7 Wall-Mounted Color Touchscreen or Russound IPK-1 Single-Gang IP Keypad, or remotely from the Russound app.
- Pre-amplifier delivers bridges audio from 16 sources to up to 16 zones for an enhanced audio experience while integrated streamer allows access to popular music streaming services and wireless smart devices
- Supports Ethernet, stereo analog, digital optical, digital coax, HDMI ARC, and USB audio sources
- Stream audio via Wi-Fi or Bluetooth using Apple AirPlay, Google Cast, or Spotify Connect and easily connects with popular audio streaming services
- Mounts onto a shelf or within a 19" rack
- Control from the Russound XTS7 Wall-Mounted Color Touchscreen, IPK-1 Single-Gang IP Keypad, and the Russound app
- Network with 5 other Russound SMZ amplifiers to reach a maximum of 48 zones
Why You Would Use This Product:
The Russound 16-Channel Matrix Pre-Amplifier with Built-In Streamer is perfect for homeowners and businesses looking for an advanced and versatile multi-room audio system. In a residential setting, this controller amplifier allows family members to play different music in various rooms, whether streaming from popular music services or listening to internet radio, creating a personalized audio experience for everyone. For commercial spaces such as restaurants, offices, or retail environments, this device enables ambient music in each area while offering the flexibility to adjust the audio source depending on the location, which can improve the customer or employee experience.
In The Box:
- SMZ16PRE Controller Amplifier
- 2 x removable Wi-Fi/Bluetooth Antennas
- 3 x IR Emitters with 6ft cables
- 6 ft (1.82 m) power cord
- Set of rack mount ears with mounting screws
- Owner's Manual
Tech Specs
- Part Number: SMZ16-PRE
- UPC: 612934853838
- Network Connectivity: Wired/Wi-Fi 802.11ac
- Supports Low Latency Synchronization: Yes
- Advanced DSP with 7-band EQ: Yes
- Supports Optional BTC-2X: Yes
- Russound Certified Installer Required: Yes
- Rack Mount Ears Included: Yes
- Audio Source Inputs: maximum of 8 total inputs
- 8 Stereo Analog
- 6 Digital Optical
- 4 Digital Coax
- 1 HDMI
- 1 USB
- Audio Outputs: 16 line level or source loop selectable
- IR Outputs: Up to 9 routed, with 8 shared outputs and 1 common
- Global Trigger Out: Up to 5 routed, with 4 shared outputs and 1 global
- Home Theater Trigger (HDMI ARC): In/Out, 12VDC (pass-through)
- Paging Trigger: In, 12VDC
- Speaker Connections:
- 16 Stereo L/R Source Loop Outputs
- 16 Stereo L/R Line Outputs
- Communication Ports:
- 1 USB
- 1 Dedicated Ethernet RJ-45, 10/100 Base T for BTC-2X In/Out
- 2 Ethernet RJ-45, 10/100 Base T
- 2 RJ-45 RNET Links In/Out
- Power Supply: 100-120V / 220-240V ~ 50/60 Hz
- Dimensions: 17.1 in x 15.83 in x 3.48" (43.4 cm x 40.2 cm x 8.8 cm)
- Weight: 20.7 lbs (9.4 kg)
- Shipping Dimensions: 20.9 in x 19.7 in x 9.25 in (53 cm x 50 cm x 23.5 cm)
- Shipping Weight: 27.56 lbs (12.5 kg)
- Warranty: 2-Year Limited
