Russound 8-Channel Digital Amplifier
Product Description
The Russound 8-Channel Digital Amplifier is a versatile digital amplifier designed to accommodate virtually any kind or sized audio system in order to optimize your home audio experience. This amplifier supports eight channels (4 paired zones) of connected speakers, each of which can be individually customized to maximize the performance of connected audio devices. Dual bus inputs can play audio across all zones or each zone can play audio from their own dedicated audio source. Zones and channels can also be bridged together to deliver robust audio to more powerful speakers in larger environments.
- Provides ample power to drive speakers in up to eight channels across 6 zones or rooms
- Supports up to 8 audio sources: dual bus inputs or 1 dedicated line level input per zone; each zone can select its active input
- Individually configure each zone's settings to deliver the best quality audio possible
- Bridgeable channels allow for increased power output to larger or more demanding speaker setups
- Compatible with a range of control systems and automation platforms, enabling seamless integration and centralized control of your audio system.
- 1U Rack Size saves space in standard equipment racks to leave room for expansion
Why You Would Use This Product:
With the Russound 8-Channel Digital Amplifier, you can create a customized multi-room audio system that caters to your unique listening preferences. Whether you're hosting a party and want music to flow seamlessly throughout your home, or you simply enjoy having different audio zones for different activities, this amplifier offers the power and flexibility to bring your audio vision to life. Install speakers in your living room, kitchen, patio, and bedrooms, and use the Russound D890 amplifier to power them all with rich, high-fidelity sound.
In The Box:
- D890 Digital Amplifier, 8-Channel
- 6 Ft. Power Cord
- Set of 4 Removable Speaker Connectors
- Set of Rack Mount Ears
- Manual
Tech Specs
- Part Number: D890
- UPC: 612934853906
- Amplifier Channels: 8 channels 4 independent zones
- Bridge: Yes
- Filter Options: High Pass, Low Pass, Full Range
- Power Output:
- 4 Ohms: 90W /Channel, 1kHz, One Zone Driven
- 8 Ohms: 45W /Channel, 1kHz, One Zone Driven
- 8 Ohms Bridged: 180W, 1kHz One Zone Driven
- Frequency Response: 20Hz to 20kHz ±3dB at 1W output into 4 or 8 Ohms
- Input Sensitivity:
- 620 mV for 90W @ 1kHz 4 Ohm One Zone
- 690 mV for 45W @ 1kHz 8 Ohm One Zone
- Fuse Rating: 6.3A, 250V FA
- Input Impedance: >22k Ohms Line Input
- Signal-to-Noise Ratio: >90dB A-weighted
- Trigger Inputs/Outputs: 12V, Global
- Volume Gain Adjustment: By Zone
- Line Inputs: Selectable: Bus A, Bus B, Zone
- Speaker Connectors: Detachable Screw-down, up to 12 Gauge
- Operating Temperature: -32° to 104°F (0° to 40°C)
- Operating Altitude: 0 to 9,843 feet (3000m)
- Minimum Impedance: Stereo Mode 4 Ohms, Bridge Mode 8 Ohms
- Power Requirements:
- North American Model: 115-120VAC, 60Hz (600W Max)
- International Model (D890i):220-240VAC, 50Hz (600W Max)
- Power Connector: IEC C14
- Standby Power: Less Than 0.5W
- Dimensions: 17.125(W) x 1.75 (H) x 9.75 (D) inches (43.5 x 4.4 x 24.8 cm)
- Weight: 9 lbs (4.1 kg)
- Shipping Dimensions: 20.2 (W) x 4.9 (H) x 14.3 (D) inches (51.33 x 12.5 x 36.3 cm)
- Shipping Weight: 11.8 lbs (5.3kg)
- Warranty: 2-Year Limited
