Seco-Larm Enforcer Track-Mount Overhead Door Magnetic Contact Switch (Open Box)

$13.52 $17.98
SKU: SESM4201LQ_OB

1 available at this price.

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Product Description

  • Used for overhead doors in both industrial and residential situations where a wide gap is present
  • Adjustable to fit most door-channel widths
  • Rugged aluminum housing
  • 36-inch (91cm) wire leads enclosed in armored cable
  • Contact Type: SPST, iridium-plated to have a high melting point and Vickers hardness for higher power handling and longer expected life
  • For closed loop circuits
  • 3-inch (76mm) Gap
  • Mounting bracket included
  • Lifetime limited warranty

In The Box:

  • Contact Switch
  • Magnet
  • Installation Hardware
  • Mounting Bracket
  • Manual

Tech Specs

  • Part Number: SM-4201-LQ
  • UPC: 676544016083
  • Circuit Type: Closed loop
  • Operation Gap: 3-inches (76mm)
  • Material:
    • Case: Aluminum
    • Terminal: 36-inches (91cm) armored leads
  • Contacts: Iridium-plated
  • Contact Rating:
    • 0.1A at 100VDC (max)
    • 1.0A at 10VDC (max)
    • 10W (max)
  • Operating Temperature: -15° to 160° F (-25° to 70° C)
  • Switch Cycles: 50 Million (0.1mA at 5VDC)
  • Magnetic Type: Ferrite
  • Dimensions:
    • Switch: 3-7/64 x 2-19/32 x 1-13/16 inches (79 x 66 x 46 mm)
    • Magnet: 3-7/32 x 3-17/32 x 1-3/4 inches (82 x 90 x 44 mm)
  • Certifications: RoHS
  • Warranty: Lifetime Limited
