Sensaphone 1800 Remote Monitoring System

$981.00
SKU: PHFGD1800CD

Order now and we'll ship usually within 3-5 business days.

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

This is a heavy and/or oversized item and does not qualify for our shipping promotion.

Product Description

The Sensaphone 1800 Monitoring Systems offer an easy and inexpensive way to monitor up to eight environmental inputs under the harshest conditions. Previously called "auto dialers," these systems notify you if they sense undesirable temperatures or other conditions. You can record custom alerts and receive alarm messages in your own voice.

In addition to dry contact, 2.8K, and 10K thermistor inputs; 4-20mA support allows for third-party sensor integration. Nonvolatile memory retains system settings, programming, and logs in the event of power failure. You can call in by phone to get the status of each monitored condition.

  • Simple, convenient, cost-effective remote monitoring ideal for greenhouse and agriculture applications
  • Rugged, weatherproof NEMA-4X enclosure offers protection in harsh environments
  • Receive voice alerts and alarm notifications over standard telephone lines
  • Auto dialer: Notifies up to eight people by voice phone call in the event of an alarm
  • Up to eight external sensors monitor temperature, humidity, water and more
  • Included relay output can switch local devices on/off based on alarm activity
  • Temperature-sensing range of -109° to -168°F (-85° to -76°C)
  • Record custom voice alerts and receive alarm messages in your own voice
  • Made in USA

In The Box:

  • Sensaphone 1800 System
  • Power Supply

NOTE: External sensors and backup batteries not included.

Available for sale only in the U.S.

Tech Specs

  • Part Number: FGD-1800-CD
  • Communication Method: Phone Line
  • Number of Inputs: 8
  • Input Types: Contact, 2.8K, 10K , 4-20mA
  • Temperature Sensing Range: -109° to 168°F ( -85° to 76°C)
  • Output Relay:
    • One universal input relay
    • Manual or automatic alarm switching
  • Remote Access:
    • Call in to check status and make programming changes
    • Microphone for listen in status
  • Local Access:
    • Keypad and speaker for local programming
    • Easy voice prompted programming
    • Password Protected
    • Recent alarm history playback
    • LEDs
  • Alarm Notification: Eight custom voice phone calls
  • Power Supply:
    • Plug in power supply also monitors for power failures
    • Internal battery backup
  • Dimensions: 8.0 x 12.3 x 5.6 inches (203 x 312 x 142mm)
  • Weight: 6lbs (2.72kg)
  • Battery Backup Time: 24 Hours
  • Standards:
    • FCC Part 15 Class A, USA Emission Standards
    • FCC Part 68 (47 C.F.R. Part 68), USA Telecommunications Standards
    • ICES-003 Issue 4 Class A, Canadian Emission Standards
    • Complies with CS-03 Issue 8, Canadian Telecommunications Standards
    • NRTL Listed for compliance to UL60950-1, USA Safety Standards
    • NRTL Listed for compliance to CSA C22.2 No. 60950-1, Canadian Safety Standards
  • Enclosure:
    • Solid Door Enclosure:
      • ABS/PC Blended Plastic, UL94-5VB Flammability rating
      • NEMA Type 1, 2, 3, 3R, 4, 4X, 12 & 13, IEC529, IP66
    • Clear Door Enclosure:
      • ABS/PC blended plastic, UL94-5VB flammability rating; UV stabilized
      • NEMA Type 1, 2, 3, 3R, 4, 4X, 12 & 13, IEC529-IP65
  • Warranty: 2 Years
