Arlington Grounding Bridge, Zinc
Product Description
Arlington's heavy-duty Grounding Bridge provides reliable intersystem bonding between power and communication grounding systems. They have four termination points; one more than required by 250.94 of the 2008 NEC. Available in zinc (GB5) and bronze (GBB5 and GBB50), our new Grounding Bridge has the capacity to handle multiple hookups of communications systems; telephone, CATV or satellite dish.
- For indoor or outdoor use
- Intersystem Bonding and Grounding Conductors: All accommodate #14 to #4 copper or aluminum, solid or stranded
- Grounding Electrode Conductor or Equipment Grounding Conductor: GB5 and GBB5 accept #6 to #2. GBB50 accepts #6 to #1/0. All can be used with copper or aluminum, solid or stranded.
- Fast, simple installation
- Easy access for inspections
- For good looks – textured, paintable plastic cover
Tech Specs
- Material: Zinc
