On-Q/Legrand 10x8 Combo Module RJ45 with RJ31X
Product Description
The 10x8 combo distributes up to 4 incoming telephone lines (RJ45) to 10 locations, and 1 GHz video to eight locations. The innovative mounting bracket includes a detachable platform for the coax splitter, allowing easy access to all termination ports during installation. The platform attaches securely to create a compact form factor that takes up minimal space in the enclosure.
- Eight way, 1 GHz passive digital HDTV cable splitter
- Coaxial splitter is compatible with existing and future networks such as VoIP and DOCSIS 3.0
- 10 way, 4-line RJ45 telecom module
- Includes RJ31X line seizure port for security installations
- Mounting infrastructure included
- UL Listed
Tech Specs
- Cable Type: Cat 5, Cat5e, Cat 6, Coaxial
- Color: Black
- Connection Type: RJ45, F Connector, RJ31X
- Type: Telecom/Video Module
- Surge Protected: Splitter: Surge Withstand 6 kV Ring Wave Surge per IEEE C62.41 Category A3
- Frequency: 5 MHz-1002 MHz
- Material: 18 Gauge Cold Rolled Steel
- Mounting: Enclosure
- Ohm Value: Splitter: Nominal impedance 75 Ohms
- Operating Temperature: 40 to 140 degrees F (-40 to 60 degrees C)
- Receptacle Type: RJ45(10), F Connector(8), RJ31X(1)
- Number of Receptacles: 19
- Dimensions: 6(W) x 5(H) x 3.1(L) inches (15.2 x 12.7 x 7.9 cm)
- Weight: 1.485 pounds
- UL Standard: Yes
- UN SPS C: 43222819
