On-Q/Legrand 10x8 phone & Video Combo Module, 110 with RJ31X (1Ghz)
Product Description
The 10x8 combo distributes up to 4 incoming telephone lines (110 IDC Punchdown) to 10 locations, and 1 GHz video to eight locations. The innovative mounting bracket includes a detachable platform for the coax splitter, allowing easy access to all termination ports during installation. The platform attaches securely to create a compact form factor that takes up minimal space in the enclosure.
- Eight way, 1 GHz passive digital HDTV cable splitter
- Coaxial splitter is compatible with existing and future networks such as VoIP and DOCSIS 3.0
- 10 way, 4-line 110 IDC Punchdown telecom module
- Includes RJ31X line seizure port for security installations
- Mounting infrastructure included
- UL listed
Tech Specs
- Part Number: CO1110
- Type: Telecom/Video Module
- Material: 18 Gauge Cold Rolled Steel
- Color: Black
- Mounting: Enclosure
- Cable Type: Cat5, Cat5e, Cat6, Coaxial
- Receptacle Type: IDC(10), F Connector(8), RJ31X(1)
- Number of Receptacles: 19
- Ohm Value: Splitter: Nominal impedance 75 Ohms
- Surge Protected: Splitter: Surge Withstand 6 kV Ring Wave Surge per IEEE C62.41 Category A3
- Operating Temperature: -40° to 140°F (-40° to 60°C)
- Dimensions: 6.0(W) x 5.0(H) x 3.1(L) inches (15.2 x 12.7 x 7.9 cm)
- Weight: 1.53 pounds
- UL Standard: Yes
- UN SPS C: 43222819
