Seco-Larm Enforcer Overhead Door Magnetic Contact, Closed Loop
Product Description
- For closed loop circuits
- Switch contained in low-profile cast aluminum housing anchored directly to the floor, and curved so heavy vehicles can cross over without damaging it.
- Magnet enclosed in round bracket
- 24-inch wire leads enclosed in stainless-steel cable
Tech Specs
- Circuit type: Closed loop
- Operation gap: 2-3/4" (70mm)
- Material:
- Switch: Heavy-duty cast-aluminum case
- Terminal: 24" (61cm) armored leads
- Magnet: Enclosed in epoxy in aluminum housing
- Contacts: Deactivated rhodium on gold under-plating
- Contact rating:
- 0.1A@100VDC (max)
- 1.0A@10VDC (max)
- 10W (max)
- Temperature: -15°~160°F (-25°~70°C)
- Switch cycles: 50 Million (0.1mA@5VDC)
- Switch dimensions: 4-11/32 x 1-3/4 x 2-7/64 inches (110 x 44 x 11 mm)
- Magnet dimensions: 3-35/64 x 15/16 x 127/64 inches (90 x 33 x 37mm)
- Magnet type: Alnico 5
