2GIG Z-Wave 700 Programmable Thermostat
Product Description
The 2GIG Smart Z-Wave 700 Programmable Thermostat gives you the utmost in HVAC control and convenience. This thermostat simplifies heating and cooling within your home with Z-Wave automation and remote control through your compatible smart device. The thermostat's compatibility with most Z-Wave hubs and conventional HVAC ensures seamless integration into virtually any home. In addition to commanding standard HVAC applications, the Thermostat can also control HVAC humidifier/dehumidifier features and be included in automated scenes with other Z-Wave connected devices.
Features:
- Capacitive touch buttons and bright LED screen provide clear info and controls
- Display shows current system mode, temperature set points, humidity, and time
- Z-Wave thermostat supports 2-stage cooling, 3-stage heating, and humidity control
- Seamless adjust comfort settings from the panel, thermostat, or mobile app
- Set automation rules for temperature changes
- Z-Wave 700 compatibility includes extended wireless range, faster operation, and longer battery life
- SmartStart Support and S2 authentication security
- 24VAC or AA battery powered
In The Box:
- Thermostat
- 4 x AA Batteries
- Mounting Hardware
- Install Manual and Quick Start Guide
NOTE: Not compatible with 120/240 VAC systems. Batteries are not required for backup power.
Tech Specs
- Part Number: 2GIG-STZ1-345
- Programmable thermostat for:
- 24VAC 3H/2C non-heat pump
- 24VAC 3H/2C heat pump systems with humidifier/dehumidifier support
- Room Temperature Measurement:
- Temp. Scale: Fahrenheit / Celsius (user selectable)
- Temp. Range: 32 ~ 122°F (0 ~ 50°C) (Operating Temperature Limit)
- Temp. Accuracy: ± 1°F (0.5°C)
- Temperature Setpoint Range:
- Heat Set Point: 32 – 90 °F (0 – 32 °C)
- Cool Set Point: 61 – 122 °F (16 – 50 °C)
- Setting resolution: 1°F (0.5°C)
- Standard Systems:
- 1 Stage Heating and Cooling
- 2 Stage Heating and Cooling
- Heat Pump Systems:
- 1 Stage Heating and Cooling
- 2 Stage Heating and Cooling
- 2nd or 3rd Stage Aux Heating (Electric Heat Strips)
- Fan Control: Auto/On
- Output Relays:
- Latching type relay for all switching.
- Seven Relays (C, RC, RH, W1, W2/O, Y1, Y2, G, W3, HUM+, HUM-)
- Control Logic:
- Compressor short cycle protection: 5 – 9 minutes, user configurable
- Minimum Run Time: 3 minutes (gas/electric heating), 4 minutes (compressor operation)
- Program: OFF, Heat, Cool, Auto, E-Heat
- Power Supply:
- AC: 18-26VAC 60Hz (R and C)
- 4x AA size battery (6VDC)
- Operating Temperature Range: 32° to 122° F (0° to 50° C)
- Operating Humidity: 10-90 percent Non-Condensing
- Size: 5.75 x 4.5 x 1 in (14.6 x 11.4 x 2.5 cm)
- Weight: 1lb (0.45kg)
- Certification: FCC Part 15, Industry Canada, Z-Wave
- Warranty: 1-Year Limited
