Russound 8 Source, 8 Zone Controller Amplifier with Built-in Streamer
Product Description
The Russound 8 Source, 8 Zone Controller Amplifier with Built-in Streamer delivers high-quality audio from 8 connected sources to up to 8 zones and sources in a home or business. This advanced multi-room audio controller allows users to enjoy different audio in separate zones or synchronize audio throughout the entire property. With its powerful built-in amplifier, the SMZ8 provides clear, dynamic sound that enhances listening experiences, supporting various types of media and audio streaming platforms. The integrated streamer provides access to popular audio streaming services, and facilitates use of wireless streaming protocols including Apple Airplay, Google Cast, Spotify Connect, and Bluetooth in order to make it easier than ever to play your favorite audio from any device or audio source. The Controller Amplifier can be commanded within your home or business from a Russound XTS7 Wall-Mounted Color Touchscreen or Russound IPK-1 Single-Gang IP Keypad, or remotely from the Russound app.
- Audio amplifier delivers clear and dynamic sound to 8 zones from up to 8 sources for an enhanced audio experience while integrated streamer allows access to popular music streaming services and wireless smart devices
- Supports Ethernet, stereo analog, digital optical, digital coax, HDMI ARC, and USB audio sources
- Stream audio via Wi-Fi or Bluetooth using Apple AirPlay, Google Cast, or Spotify Connect and easily connects with popular audio streaming services
- Mounts onto a shelf or within a 19" rack
- Control from the Russound XTS7 Wall-Mounted Color Touchscreen, IPK-1 Single-Gang IP Keypad, and the Russound app
- Network with up to 5 additional Russound SMZ series amplifiers to reach a maximum of 48 zones
Why You Would Use This Product:
The Russound 8 Source, 8 Zone Controller Amplifier with Built-in Streamer is perfect for homeowners and businesses looking for an advanced and versatile multi-room audio system. In a residential setting, this controller amplifier allows family members to play different music in various rooms, whether streaming from popular music services or listening to internet radio, creating a personalized audio experience for everyone. For commercial spaces such as restaurants, offices, or retail environments, this device enables ambient music in each area while offering the flexibility to adjust the audio source depending on the location, which can improve the customer or employee experience.
In The Box:
- SMZ8 Controller Amplifier
- 6 ft (1.82 m) Power Cord
- Set of rack mount ears with mounting screws
- 2 x removable Wi-Fi/Bluetooth Antennas
- 6 x Removable, screw-down 5 conductor speaker terminals
- Owner's Manual
Tech Specs
- Part Number: SMZ8
- UPC: 612934853821
- Network Connectivity: Wired/Wi-Fi 802.11ac
- Supports Low Latency Synchronization: Yes
- Advanced DSP with 7-band EQ: Yes
- Supports Optional BTC-2X: Yes
- Russound Certified Installer Required: Yes
- Rack Mount Ears Included: Yes
- Audio Source Inputs: maximum of 8 total inputs
- 8 Stereo Analog
- 3 Digital Optical
- 2 Digital Coax
- 1 HDMI
- 1 USB
- Audio Output(s): 6 Speaker Level 40W/ch (8 line level, fixed or variable selectable)
- Watts per Channel: 40W
- 1kHz into 8 ohms with <5% THD+N
- 2 channels at full power
- 10 channels at 1/8th
- Speaker Connections:
- 6 detachable, screwless 4 pole connectors
- 8 Stereo L/R Source Loop Outputs
- 8 Stereo L/R Line Outputs
- Frequency Response: 20Hz-20kHz ±1 dB at 1W output into 8 ohms
- Minimum Impedance: 8 ohms
- Total Harmonic Distortion: <0.05%, 1W output into 8 ohms 20Hz-20kHz
- Signal to Noise Ratio: 93 dB unweighted, 96 dB A-weighted
- Common Trigger: Out, 12VDC, @100mA
- Home Theater Trigger: In/Out, 12VDC (pass-through)
- Paging Trigger: In, 12VDC
- IR Outputs: Up to 6 routed, with two shared outputs and 1 common
- Communication Ports:
- 1 USB
- 1 Dedicated Ethernet RJ-45, 10/100 Base T for BTC-2X In/Out
- 2 Ethernet RJ-45, 10/100 Base T
- 2 RJ-45 RNET Links In/Out
- Power Supply: 100-120V / 220-240V ~ 50/60 Hz
- Dimensions: 17.1 in x 15.83 in x 5.26 inches (43.4 cm x 40.2 cm x 13.4 cm)
- Weight: 18.4 lbs (8.35 kg)
- Shipping Dimensions: 20.9 in x 19.7 in x 11 in (53 cm x 50 cm x 28 cm)
- Shipping Weight: 25.6 lbs (11.6 kg)
- Warranty: 2-Year Limited
