ABB-Welcome Video Indoor Station, 7 Inch

$401.45
SKU: ABM22381x

Please Select Option To View Availability

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Product Description

The 7" panel is the new member of ABB-Welcome indoor world. It features a 7 inch capacitive touchscreen with a glossy frameless glass surface. The new panel has 5 keys to control main video door entry functions: accept the call, door release, mute audio, surveillance, and a fifth programmable button for customizable control.

The touch panel makes communication accessible across your home and provides several automation and security features. View images from multiple outdoor stations or surveillance cameras connected to a single Indoor Station. Onboard memory stores guest history and audio/video footage from outdoor stations, voicemail and answering machine messages and custom doorbell tones, songs, and alerts. Built-in LEDs help you notice missed calls, device status, and alert notifications.

Place the touch panel anywhere in your home using surface-mount, flush-mount, or desktop installation.

Feature:

  • Display and record the video image from outdoor station or external cameras
  • Different bell sounds are adjustable for door and floor ringing
  • Five different bell sounds are available and also you can play your favorite ringtone from SD card (not included)
  • Leave message to family members or visitors when out of home
  • "Doctor" function for automatic unlock
  • Internal call to other stations in your home or residential/office building
  • Send SOS alarm to guard unit

In The Box:

  • Video Indoor Station

NOTE: For indoor use only. Requires 2-wire connection to an ABB System Controller, sold separately. Also requires use with at least one outdoor station that includes an audio module OR at least one additional indoor station, and at least one camera to provide video. Installation hardware and SD card not included.

Tech Specs

  • Part Number:
    • Black: M22381-B
    • White: M22381-W
  • Display size: 7" capacitive touchscreen
  • Display resolution: 1024 x 600
  • Operating Temperature: -14° to 131°F (-10° to 55°C)
  • Storage Temperature: -40° to 158°F (-40° to 70°C)
  • Protection: IP30
  • Single-Wire Clamps: 2 x 0.28 mm2 – 2 x 0.75 mm2
  • Fine-Wire Clamps: 2 x 0.28 mm2 – 2 x 0.75 mm2
  • Bus Voltage: 20-30V
  • Standby current: ≤12 mA @ 24 V DC
  • Operating current: ≤330 mA @ 24 V DC
  • Dimensions: 6.39 x 7.79 x 0.66 inches (198.5 x 162.3 x 17 mm)
  • Warranty: 2 Year

System Capacity

  • 9 Guard Units per System
  • 60 Buildings per System
  • 250 Indoor Stations per Building
  • 9 Outdoor Stations per Building (including gate and other outdoor stations)
  • 2 Locks per Outdoor Station
