Seco-Larm Enforcer Wireless Video Door Phone Kit
Product Description
The Seco-Larm Enforcer Wireless Video Door Phone Kit allows you to monitor and communicate with guests at an entryway to your home. When a guest or visitor presses the doorbell button on the video door phone unit, you can respond using an indoor wireless LCD monitor to see who is requesting entry, speak with the caller, take a photo, and decide whether to grant entry. The indoor LCD monitor can communicate with a video door phone up to 492 feet (150 meters)* away. This kit can be expanded for larger properties with up to two additional indoor monitors and one additional camera, all sold separately. If multiple monitors are set up, then the system can also be used as an intercom system between each monitor.
- Talk with visitors and unlock doors or gates via the indoor monitor and outdoor video door phone
- Monitor's rechargeable battery allows convenient communication with visitors while moving around the premises
- Connect up to 2 additional monitors and 1 additional camera (sold separately)
- Intercom calling between paired monitors
- Egress input allows the door phone to be connected to a Request to Exit Plate or other egress device
- Camera has a 170° field of view with adjustable pan and tilt angle to accommodate a variety of installations
- Camera has built-in IR LEDs for nighttime operation
- Camera's built-in PIR sensor activates camera to take photos or record video of approaching visitors
- Tamper switch triggers alarm if camera is removed from base
In The Box:
- Monitor (DP-266-M7Q)
- Camera (DP-266-CAQ)
- Monitor battery
- Camera battery
- Camera screw cover
- Camera screw
- DC Jack with pigtail
- Camera mounting hood bracket
- Monitor wall-mount bracket
- AC Power adapter with DC plug (for monitor)
- AC Power adapter with DC plug (for camera)
- 3 x Camera mounting screws
- 3 x Camera mounting screw anchors
- 4 x Monitor wall-mount bracket screws
- 4 x Monitor wall-mount screw anchors
- Manual
NOTE: Actual range between the monitor and camera may vary depending on the installation and operating environment.
Tech Specs
- Part Number: DP-266-M3Q
- UPC: 676544022275
- Type: Color camera
- Chip: CMOS
- Resolution: 640 TV Lines
- Lens: 2mm
- Field of View: 170°
- Camera Angle Adjustment: Up to 20° any direction
- IR LED Range: 5' (1.5m)
- IR LED Frequency: 940nm
- PIR Detection Range: 9' (3m)
- PIR Detection Angle: 170°
- Display: 3-3/8 inches (86mm) TFT
- Relock Delay: 3/6/8 Seconds
- Relay Output: 3A@24VAC/24VDC
- Operating Voltage: 9~16 VAC/5~16 VDC
- Current Draw:
- Active: 300mA@12VDC
- Standby: 15mA@12VDC
- Battery Life:
- Active: ~7 Hours
- Standby: ~60 Days
- Operating Frequency: 2402~2480 MHz
- RF Power: 120mW
- Wireless Range: 492 feet (150 meters)
- Dimensions (with Bracket): 3-1/8" x 5-11/16"x 1-15/16" inches (80 x 144 x 50 mm)
- Weight: 4.3-oz (122g)
- Operating Temperature: 14° to 122° F (-10° to 50° C)
- Credentials: FCC, CE, RoHS
- Warranty: 1-Year
Monitor
- Display: 7" (178mm) TFT
- Operating Voltage:
- Adapter: 12VDC
- Battery: 3.7VDC
- Current Draw:
- Active: 600mA@3.7VDC
- Standby: 5mA@3.7VDC
- Battery Life:
- Active: ~2.5 Hours
- Standby: ~7 days
- Antenna Gain: 0dBi
- Modulation Type: GFSK
- Operating Frequency: 2402~2480MHz
- RF Power: 120mW
- Wireless Range: 492 ft (150 m) line of sight
- Operating Temperature: 14° to 122° F (-10° to 50° C)
- Dimensions: 8" x 6" x 1-1/8 inches (203 x 153 x 27 mm)
- Weight: 1.2-lbs (544g)
