Uniview 1 HDD Network Video Recorder, 4 Channel, 4 PoE

$479.00
SKU: UNNVR30108BP8IQ

Temporarily unavailable for purchase. Please contact customer service for more information.

Shop More From Uniview

WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Product Description

The Uniview 1 HDD Network Video Recorder (NVR), 4 Channel, 4 PoE provides reliable, high-definition video recording and centralized management for small-scale security camera systems. This NVR stores recorded footage or streams live feeds from 4 IP cameras through built-in PoE ports, simplifying installation by providing both power and data through a single Ethernet cable. Through compatible cameras and a sufficient Internet network, the NVR can record or livestream footage between resolutions of CIF (352 x 288) and 4K (4000 x 3000) at 30fps. The Uniview NVR records and stores high-resolution video footage on a single 10TB hard drive. With intelligent search and playback functions, users can quickly locate important footage, improving efficiency during security reviews.

  • Supports up to 4 IP cameras with built-in PoE ports for simplified installation; Supports 3rd party cameras compliant with ONVIF and RTSP protocols
  • Records or streams live footage in resolutions up to Full 4K (4800 x 2688) resolution at 30 fps
  • Supports one 10TB drive for efficient storage of recorded video plus 1 SATA port for optional expansion; supports Ultra 265, H.265, and H.264 compression
  • Display livestream or recorded footage through HDMI and VGA outputs
  • Intelligent VCA detection, search, and playback functions for enhanced subject detection and early warning

Why You Would Use This Product:

The Uniview 1 HDD Network Video Recorder, 4 Channel, 4 PoE, is ideal for anyone looking to set up a reliable and efficient security system with minimal hassle. In residential applications, the NVR allows homeowners to easily connect and manage up to four security cameras, ensuring comprehensive coverage of key areas like entrances, driveways, and backyards. The built-in PoE ports simplify installation by reducing the need for separate power cables, making it an excellent choice for DIY setups. For commercial environments, such as small offices, retail stores, or warehouses, this NVR provides an efficient way to monitor critical zones and store important footage securely. Its remote access feature allows business owners to check in on their property from anywhere, ensuring peace of mind even when they're offsite.

In The Box:

  • Uniview NVR301-04B-P4-IQ Network Video Recorder
  • Power Adapter
  • USB Mouse
  • Quick Start Guide

Notes:

  • Hard drives for storage are sold separately.
  • Professional installation is recommended.

Tech Specs

  • Part Number: NVR301-08B-P8-IQ
  • UPC: 810093329991
  • Warranty: 3-Year; Hard drives not covered

Decoding

  • Decoding Format: Ultra 265, H.265, H.264
  • Decoding Capability Description: The resolution of each channel cannot exceed 8192 pixels in length and 4096 pixels in width
  • Decoding Capability:
    • Smart Off：2 x 12MP@30, 2 x 4K@30, 4 x 4MP@30, 8 x 1080P@30
    • Smart On：2 x 4K@30, 4 x 4MP@30, 8 x 1080P@30
  • Audio Compression: G.711A, G.711U

Network

  • Incoming Bandwidth: 80 Mbps
  • Outgoing Bandwidth: 80 Mbps
  • Remote Users: 128
  • Protocols: TCP/IP, P2P, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv6, IPv4
  • Browser (Plugin): Windows: IE (IE10/11), Firefox (version 52.0 and above), Chrome (version 45 and above), Edge (version 79 and above)

Audio / Video Output

  • HDMI Output: 4K (3840 x 2160)/30 Hz, 1920 x 1080/60 Hz, 1920 x 1080/50 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz, 1024 x 768/60 Hz
  • VGA Output: 1920 x 1080/60 Hz, 1920 x 1080/50 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz, 1024 x 768/60 Hz
  • RCA Audio Output: 1 ch
  • Live View Display: 1/4/6/8/9
  • Corridor Mode Screen: 3/4/5/7/9

Audio / Video Input

  • IP Video Input: 8-ch
  • RCA Audio Input: 1 ch

Two-Way Audio

  • Two-Way Audio: 1 ch, RCA(Using the audio input and output)

Snapshot

  • FTP/Schedule/Event Snapshot: 4-ch snapshot (max. D1 (720*576) video resolution, with D1 snapshot resolution)

Recording

  • Recording Resolution: 12MP / 8MP/ 6MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P / D1 / 2CIF / CIF
  • Synchronous Playback in Local: 16 ch

Smart

  • VCA Detection by IPC: Face Detection, Vehicle Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Ultra Motion Detection (UMD), People Counting (People Flow Counting, Crowd Density Monitoring), Traffic Monitoring
  • VCA Search: Motor Vehicle Search, Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report, Heat Map, AcuSearch
  • Smart by NVR: Face Detection, Smart Intrusion Prevention (SIP), Ultra Motion Detection (UMD)
  • Smart by IPC: All channels (up to 8 images/s in total)Face Detection, Vehicle Detection, SIP, UMD, Traffic Monitoring
  • Search by Image: Support
  • SIP by NVR: 2-ch
  • UMD by NVR: 4-ch

Alarms

  • General Alarms: Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection
  • Alert Alarms: IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal

GUI Language

  • 38 Languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian

Hard Disk

  • SATA: 1 SATA Interface
  • Capacity: Up to 10TB for each HDD(The maximum HDD capacity varies with environment temperature and hard disk size)

External Interface

  • Network Interface: 1 RJ45 10M/100M self adaptive Ethernet Interface
  • USB: Front panel: 1 x USB 2.0; Rear panel: 1 x USB 3.0
  • RS232: N/A
  • RS485: N/A
  • Alarm In: N/A
  • Alarm Out: N/A
  • Power Supply: DC 52 V/1.8 A
  • Power Switch: N/A

PoE

  • Interface: 8 RJ45 10 M/100 M self-adaptive Ethernet Interface
  • Max Power: Max 30W for single port, Max 75W in total
  • Supported Standard: IEEE 802.3at, IEEE 802.3af

Working Environment

  • Working Temperature: 14 to 131° F (10 to 55° C)
  • Working Humidity: ≤ 90% RH (non condensing)
  • Power Consumption (without HDD): ≤ 12W
  • Dimensions:
    • Weight (without HDD): ≤ 2.7Kg (6.0 lb)
    • Rack Height: 1U
    • Dimensions: 260mm x 222mm x 47mm (10.2" x 8.7" x 1.8")
  • Certifications: CE; FCC; UL; RoHS; WEEE
    • CE: EN 55032, EN 61000 3 3, EN IEC 61000 3 2, EN 55035
    • FCC: Part 15 Subpart B
