Uniview NSW3000 Series Cloud Managed Ethernet PoE Switch, 16 Port, 250W
Product Description
The Uniview NSW3000 Series Cloud Managed Ethernet PoE Switch, 16 Port, 250W provides reliable and scalable network connectivity for Power over Ethernet (PoE) devices. This cloud-managed switch enables centralized configuration, management, and monitoring of multiple devices, streamlining network operations for IT professionals. Equipped with 16 PoE ports delivering a total power budget of 250W, it efficiently powers various devices such as IP cameras, VoIP phones, and wireless access points, reducing the need for separate power sources. The switch supports an extended transmission range of up to 250 meters in Extend mode, facilitating flexible deployment in expansive environments. With advanced security features, intelligent traffic management, and automatic device detection, the Uniview NSW3000 Series switch ensures optimized network performance and reliability.
- 16 PoE ports with a total power budget of 250W for powering multiple network devices
- Cloud-based management for remote configuration and real-time monitoring
- Extended transmission range up to 250 meters in extend mode for flexible deployment
- Advanced security features including port isolation and access control for enhanced data protection
- Intelligent traffic management with port priority and QoS support for optimized network performance
- Durable all-metal casing ensuring reliability and longevity
Why You Would Use This Product:
The Uniview NSW3000 Series Cloud Managed Ethernet PoE Switch, 16 Port, 250W, is an ideal networking solution for both residential and commercial applications requiring reliable connectivity and centralized management. In residential settings, it simplifies the integration and powering of smart home devices, security cameras, and home automation systems to your local network to ensure seamless operation. This switch provides efficient power distribution and data management of smart devices, security cameras, and automation systems to a local network. The cloud-based management platform allows IT administrators to remotely configure, monitor, and troubleshoot the network, enhancing operational efficiency and reducing downtime. Whether for expanding network infrastructure, deploying IP surveillance, or integrating VoIP systems, the Uniview NSW3000 Series switch offers a scalable and secure solution to meet diverse networking needs.
In The Box:
- Managed Ethernet PoE Switch, 16 Port
- Power Cord
- Quick Install Guide
Tech Specs
- Part Number: NSW3000-17GT1GP1GC-POE-IN
- UPC: 810093324668
- Service Port: 16 x 10/100Mbps POE port (RJ45) + 1 x Gigabit port (RJ45) + 1 x Gigabit Combo
- Switching Capacity: 7.2Gbps
- Packet Forwarding Rate: 5.36Mpps
- Packet Buffer: 4Mbit
- MAC: 16K
- Power Supply: AC 100V to 240V, 50/60Hz
- PoE Standard: IEEE802.3af/at
- PoE Power: Maximum Total Power: 250W
- Maximum: PoE power for Single port: 30W
- PoE Power Supply Mode:
- Mode A, 1/2+, 3/6-
- Mode B, 4/5+, 7/8-
- Priority Ports: 1 to 8
- Priority QoS: Forwards the packets from the first eight priority ports in the event of data congestion
- Fan: 1
- Operating Temperature: 32° to 104°F (0° to 40°C)
- Storage Temperature: -40° to 158°F (-40°C to 70°C)
- Operating Humidity: 10% to 90% RH, noncondensing
- Storage Humidity: 5% to 90% RH, noncondensing
- Indicator:
- Power:
- Steady On: Normal power input
- Off: Abnormal power input
- PoE:
- Off: The PoE port is not supplying power
- Steady on: The PoE port is supplying power normally
- Link/Act:
- Off: Disconnected to the port
- On: Connected to the port
- Blinking: Transmitting data
- MAX:
- Off: The total PoE power is less than 80% of the total power of the device
- Steady on: The total PoE power is higher than 85% of the total power of the device
- Ethernet:
- Supports full duplex, half duplex, and auto-negotiation working modes
- Supports port auto-negotiation rate
- Supports port priority flow control
- Supports a link aggregation group (consist of two uplink ports)
- Supports port flow statistics
- Supports enabling/disabling ports
- System:
- Allows to view the device name, device model, serial number, current version, IP address, MAC address, DNS, operation time, etc.
- Allows to edit and manage the IP address and device name
- Supports single-user management, user authentication, and password modification
- Supports manual time configuration and NTP
- Allows to view other switches information on the same network, up to 32 switches
- Allows to view the connected video devices information, up to 64 devices
- VLAN: Supports both access and trunk modes; allows up to 32 VLANs with IDs from 1 to 4095
- MAC:
- Support (up to 16K)
- Supports clearing the dynamic MAC address
- Port Loopback Detection: Support
- QoS:
- Supports port rate limitation
- Supports broadcast storm control
- PoE:
- Allows to view PoE status and power
- Allows to enable/disable PoE power supply
- Security:
- Supports port isolation (only for the downlink ports)
- Supports locking login IP address, up to 64 addresses can be locked
- Maintenance:
- Supports N:1 port mirroring
- Supports unified software configuration, management, and search
- Supports discovering the connected video devices and generating a network topology on the software
- Supports device upgrade, factory settings restoration, configuration import, configuration export, logs export, and device restart on the software
- Weight: 4.62 (2.1kg)
- Dimensions (WxDxH): 17.32 x 7.47 x 1.73 inches (440 x 189.8 x 44mm)
